Ezviz BC1C User Manual

3
- FollowtheEZVIZappwizardtonishWi-Ficonguration.
If you want to change your camera's Wi-Fi, press and hold the reset button for 5s and
repeat the steps above.
Installation
1. Installation Location
Choosealocationwithaclear,unblockedeldofviewandwithagoodwireless
signal to the camera. Please keep the following tips in mind:
• Make sure the wall is strong enough to withstand three times the weight of the
camera.
• Camera cannot be installed in front of an air conditioner or facing direct sunlight.
• Recommended installation height: 10 ft (3 m) above the ground.
Recommended installation angle: Tilt down 15 degrees.
25 ft (7.5 m)
Motion
Detection Zone
Camera Field of View
10 ft
(3m)
• Makesurethatside-to-sidetrafccrossescamera’seldofview.Thecamera’s
motionsensorismuchmoresensitivetoside-to-sidemovementacrossitseld
of view than to movement directly toward or away from the camera.
Best Detection
Poor
• It is recommended to set detection sensitivity on EZVIZ app when selecting
location. Thus you can verify if motion can be detected in the camera’s
placement and adjust the sensitivity based on the size and distance of detected
object.
2. Installation Steps
- Placedrilltemplateontoacleanandatsurface.
- (For cement wall only) Drill screw holes according to the template, and insert
anchors.
- Usescrewstoxthemountingplateaccordingtothetemplate.
- Rotate the magnetic base (Fig.1) or screw base (Fig.2) to the mouting plate.
- Mount the camera to the base.

Ezviz BC1C Specifications

General

Mounting kit	Yes
Number of cameras	1
Type	IP security camera
Operating frequency	2400 - 2483.5 MHz
Placement supported	Outdoor
Connectivity technology	Wireless
Built-in HDD	No
Flash memory	32768 MB
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS, UL ECOLOGO, WEEE
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Black, Grey
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP66
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Minimum illumination	0.2 lx
Adjustment shutter speed	Auto
Sensor type	CMOS
Optical sensor size	1/2.8 \
Battery capacity	7800 mAh
DC output current	2 A
DC output voltage	5
Power source type	Battery
Battery technology	Lithium
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Fixed focal length	2.8 mm
LED type	IR
Night vision distance	10 m
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Supported graphics resolutions	1920 x 1080 (HD 1080)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	72 Mbit/s

Weight and Dimensions

Depth	62.8 mm
Width	104.76 mm
Weight	365 g
