Ezviz BC1C User Manual

4
2
Mounting Plate
Anchor
Drill Template
Screw
Magnetic Base
Camera
Fig.1 Mount by Magnetic Base
2
Mounting Plate
Anchor
Drill Template
Screw
Screw Base
Camera
Fig.2 Mount by Screw Base
View Your Device
The App interface may change due to version update. Please refer to the actual interface.
1. Live View
When you launch the EZVIZ app, the device page displays as shown below.
You can view and listen to a live feed, take snapshots or recordings, and choose
video definition as needed.

Ezviz BC1C Specifications

General

Mounting kit	Yes
Number of cameras	1
Type	IP security camera
Operating frequency	2400 - 2483.5 MHz
Placement supported	Outdoor
Connectivity technology	Wireless
Built-in HDD	No
Flash memory	32768 MB
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS, UL ECOLOGO, WEEE
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Black, Grey
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP66
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Minimum illumination	0.2 lx
Adjustment shutter speed	Auto
Sensor type	CMOS
Optical sensor size	1/2.8 \
Battery capacity	7800 mAh
DC output current	2 A
DC output voltage	5
Power source type	Battery
Battery technology	Lithium
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Fixed focal length	2.8 mm
LED type	IR
Night vision distance	10 m
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video compression formats	H.264, H.265
Noise reduction technology	3D noise reduction
Supported graphics resolutions	1920 x 1080 (HD 1080)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	72 Mbit/s

Weight and Dimensions

Depth	62.8 mm
Width	104.76 mm
Weight	365 g
