Ezviz DP1C User Manual

3
Mounting Base
Mounting Hole
Installation
If you already have a peephole, install the device in the same
place. If not, please drill a hole of diameter about 18mm and
about 145cm distance from the ground to have a good viewing
effect.
Measure the door's
thickness and select the
appropriate screws.
Thickness Screw
35 to 60mm
60 to 95mm
95 to 105mm

Ezviz DP1C Specifications

General

LED type	IR
Best uses	Home, Office
Certification	UL / FCC / CE / WEEE / REACH / RoHS
Product color	Black, Silver
Built-in microphone	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Megapixel	1 MP
Sensor type	CMOS
Image sensor size	1/3 \
Night vision distance	3 m
Vertical field of view	136 °
Horizontal field of view	104 °
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Connectivity technology	Wireless
Input voltage	5 V
Power source type	DC
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Bell depth	48.3 mm
Bell width	71 mm
Package type	Box
Package depth	1665 mm
Package width	107 mm
Package height	80 mm
Package weight	343 g
