Ezviz T2C - Installation

4
Installation
• Thesensormustbeplacedawayfrommagneticeld,andwhendoorsorwindowsare
closed, the distance between the sensor and the magnet should be less than 20mm.
• Beforestickingthesensor,cleanthedustonthesurfaceofthedoororwindowrst.Do
not stick the sensor on limewashed walls.
• The installation instruction grooves on the sensor and magnet should be placed together
andaligned(asdisplayedinthegurebelow).
• The installation height does not exceed 1.8m.
• The working temperature range of the sensor is -10°C~55°C.
1. Select a place where the sensor can be installled.
2. Fix the sensor on the place you have selected by the double-sided tape.
3. Press the sensor for about 20 seconds.
<20mm
Installation Instruction Groove
