ES
4
43
CARACTERÍSTICAS
Componentes
Ref. Cant. Componentes del Producto
1 1 Cuerpo campana con: Mandos, Luz, Filtros
3 1 Soporte campana con grupo de aspiración
7 1 Tubo PVC
8 1 Rejilla direccionada ø 125 mm
8c 1 Reducción salida aire ø 120 mm
9 1 Arandela de reducción ø 150-120 mm
11b 2 Aleta
Ref. Cant. Componentes de Instalación
11 4 Tacos ø 10
12a 4 Tornillos 5 x 70
12b 4 Tornillos M4 x 15
12e 2 Tornillos 2,9 x 9,5
13 4 Tapón tornillos M4
Cant. Documentación
1 Manual Instrucciones
