10.1.2 Cleaning air filter
 Gently slide the air filter upwards out of its plastic holder see fig. 8.0.
 Gently rinse with water in the sink and dry with fabric towel before returning.
 Replace the filter making sure that the coarse black filter is facing the front of the fire.
 Place the fuel bed see Chapter 6.
 Place the front glass see Chapter 5.1 or 5.2.
10.1.3 Replacing transducers
!! Always press the mains switch of the Control box to the OFF position (see fig. 4.0) and disconnect
the power supply.
The transducers are fixed in the water sump with plastic clips.
 Follow the first 5 steps in Chapter 10.1.1 to gain access to the transducers.
 Press the clip back and lift the transducer upwards out of its holder.
 Place the new transducers and repeat the steps above in reverse order.
10.1.4 Cleaning mesh filter
 Turn off the water supply.
 Close the ball valves.
 Unscrew the base and clean the filter inside.
10.1.5 Replacing in-line filter
 Turn off the water supply.
 Close the ball valves.
 Replace the in-line filter.
(Place it in correct alignment, there’s a “flow” direction marking on the filter).
10.2 Resetting absorption valve (see fig. 5.0-K)
The absorption valve is located on the right front side at the bottom of the Engine.
 Take out the activated absorption pill.
 Fix the cause of the water leakage and remove any water at the bottom of the Engine.
 Place the new pill and open the absorption valve by pressing down the white clamp.
11 Technical data
Watts
W
250
Volts
V
230-240
Batteries remote
V
(2x) 1,5 AA
Water consumption
l/h
0,15
Inlet water pressure
Bar
0,5-8
Water connection
Inch
½ or ¾

Faber e-MatriX 800 Specifications

General

Brand	Faber
Model	e-MatriX 800
Category	Indoor Fireplace
Language	English
