Faber INCA SD Series - Installation Instructions

9
1
Cut out the opening in the underside of the cabinet as shown in Figure 1.
Installation Instructions
2.a
Install Roof or Wall Cap purchased separately. Connect the 6" metal ductwork to
the Roof or Wall Cap and then attach ductwork.
Ducted(infrontofVertical)
Hood 29" 35"
X 27 5/8" 33 5/8"
Y 13 9/16" 13 9/16"
0LQ
´


´


´

´
X
Y
