Fagor 3CFI-3GLSTA - Page 11

35
INSTALLATION
● prepare an opening in the worktop of a kitchen cabinet, as per the installation drawing
● connect the hob to a gas and electrical system in accordance with the instructions supplied,
● loosely attach xing brackets to the bottom of the hob,
● remove dust from the worktop, insert hob into the opening and press in rmly,
● position xing brackets (Fig.) perpendicularly to the hob's edge and tighten rmly,
● once you install the hob in the worktop, check if it operates, especially the ame failure
cut-o and igniter.
1 - Worktop
2 - Screw
3 - Bracket
4 - Hob
5 - Seal
54
321
560
490
min
40
min
70
