33
Do not install the hob above the oven without ventilation.
INSTALLATION
Do not install the hob above the oven
without ventilation.
Route electrical lead so that it does
not touch the lower guard.
Installing hob in kitchen cabinet worktop.
Installing hob in kitchen cabinet worktop
above oven.
Note.Wheninstallingthehobinthekit-
chenworktop,installapartitionpanel,as
shown on the picture. If the hob is to be
installed above a built-in oven, installa-
tionofthepartitionpanelisnotrequired.
If the hob was installed in the kitchen
worktop above the drawer, the bottom
cover of the hob must be covered with
a wooden panel or protective board for
ceramic hobs.
min 1
8
18mm
35mm
