Error solving manual.
CNC 8060
CNC 8065
·19·
(REF: 1709)
1012 'G4: the dwell cannot be programmed using K'
DETECTION During execution.
CAUSE The letter K is associated with the third axis of the channel and in this case there is
no third axis.
SOLUTION If a third axis is not desired in the channel, the dwell may be programmed directly with
a number.
1013 'G4: the dwell cannot be negative'
DETECTION During execution.
CAUSE The dwell time programmed in function G4 is negative.
SOLUTION Program a value equal to or greater than 0.
1014 'It is no t possible to program in diameters with mirror image on the face axis'
DETECTION During execution.
CAUSE The face axis (parameter FACEAXIS) cannot have both the mirror image and
programming in diameters active at the same time.
SOLUTION Check the program.
1015 'Center coordinates out of range'
DETECTION During execution.
CAUSE One of the I, J, K values is too high for the center of the circular interpolation or for
the center of rotation of the coordinate system.
SOLUTION Program a smaller value.
1016 'Negative values cannot be used when programming an axis in diameters'
DETECTION During execution.
CAUSE Negative coordinates cannot be programmed in absolute coordinates (G90) while
programming in diameters is active (parameter DIAMPROG).
SOLUTION Programming in absolute coordinates and diameters does not admit negative
coordinates.
1017 'G198: negative software limit out of range'
DETECTION During execution.
CAUSE The value of the negative software limit is too high.
SOLUTION Check the program.
1018 'G199: positive software limit out of range'
DETECTION During execution.
CAUSE The value of the positive software limit is too high.
SOLUTION Check the program.
1019 'No measurement has been taken on the requested axis (axes)'
DETECTION During execution.
CAUSE Function G101 tries to include a measuring offset in an axis that was not involved in
the measurement or the offset has been canceled (G102).
SOLUTION To include a measuring offset (G101), the axis must have carried out a measurement.
1020 'Negative ramp time'
DETECTION During execution.
CAUSE The ramp time of function G132 is negative.
SOLUTION Program a value equal to or greater than 0.
1021 'Ramp time out of range'
DETECTION During execution.
CAUSE The ramp time of function G132 is too long.
SOLUTION Check the program.
1022 'Percentage of Feed-Forward out of range'
DETECTION During execution.
CAUSE The percentage of feed forward (G134) or AC forward (G135) is too high.
SOLUTION The percentage of feed forward or AC forward must be greater than zero and smaller
than 120.
