Fagor 8065 - Page 20

Error solving manual.
CNC 8060
CNC 8065
·20·
(REF: 1709)
1023 'Wrong set number
DETECTION During execution.
CAUSE The set number of the axis is wrong.
SOLUTION The set programmed for the axis must be greater than zero and smaller than or equal
to machine parameter NPARSETS of the axis.
1024 'Set number out of range'
DETECTION During execution.
CAUSE The set number of the axis is too high.
.SOLUTION The set programmed for the axis must be greater than zero and smaller than or equal
to machine parameter NPARSETS of the axis.
1025 'Programmed distance equal to zero'
DETECTION During execution.
CAUSE Null movement in the G63 block.
SOLUTION Check the program.
1026 'Wrong circular path with the programmed radius'
DETECTION During execution.
CAUSE The radius for the circular interpolation is too small.
SOLUTION Check the program.
1027 'The starting point and the end point of the circular path are the same (infinite solutions)'
DETECTION During execution.
CAUSE Zero radius for the circular interpolation; there are infinite solutions.
SOLUTION Check the program.
1028 'The difference between the programmed center and the calculated one is too large'
DETECTION During execution.
CAUSE In a circular interpolation with function 265 active, the difference between the initial
radius and the final one exceeds the values of machine parameters CIRINERR and
CIRINFACT.
SOLUTION Check the program.
1029 'Zero radius on circular path'
DETECTION During execution.
CAUSE The possible causes are:
• Zero radius in a circular interpolation.
• Being function G265 active, the CNC calculates a zero radius based on the center
coordinates programmed in the circular interpolation.
• Function G264 being active, both center coordinates are zero.
SOLUTION The radius of a circular interpolation cannot be zero. Both coordinates of the center
of a circular interpolation cannot be zero.
1030 '#AXIS programmed without G200/G201/202'
DETECTION During execution.
CAUSE G200, G201 or G202 are missing in the block of the #AXIS instruction.
SOLUTION Check the program.
1031 '#AXIS expected'
DETECTION During execution.
CAUSE The #AXIS instruction is missing in the block of function G201.
SOLUTION Check the program.
1032 'Spindle position missing for M19'
DETECTION During execution.
CAUSE The spindle position is missing in the block of function M19.
SOLUTION Check the program.
1035 '#SLOPE: parameter out of range'
DETECTION During execution.
CAUSE The value of some parameter of the #SLOPE instruction is too high.
SOLUTION Program smaller values.
