Error solving manual.
CNC 8060
CNC 8065
·21·
(REF: 1709)
1037 'Center coordinates ignored with G0/G1/G100/G63 active'
DETECTION During execution.
CAUSE The CNC has found parameters I, J, K with function G0, G1, G100 or G63 active. The
CNC ignores these parameters.
SOLUTION These functions do not need these parameters.
1038 'Radius compensation cannot be active while measuring'
DETECTION During execution.
CAUSE The CNC tries to execute G100 while tool radius compensation is active (G41/G42).
SOLUTION Check the program.
1039 'There is a previous measurement value for the axis (axes)'
DETECTION During execution.
CAUSE The CNC tries to carry out a measurement (G100) on an axis that has a previous
measuring offset.
SOLUTION Use function G102 to cancel the measuring offset included in the axis.
1040 'Home search not allowed on an axis in G201'
DETECTION During execution.
CAUSE The CNC cannot be home an axis that is in additive manual mode (G201).
SOLUTION Use function G202 to cancel the additive manual mode of the axis in order to home
it. After the home search, activate the additive manual mode (G201) again.
1041 'Corrected circular path center out of range'
DETECTION During execution.
CAUSE In a circular interpolation programmed either with a radius and the coordinates of the
end point or with the coordinates of the middle point, end point and having function
G265 active.
The coordinates of the center of the interpolation calculated by the CNC are too large.
The coordinates programmed for the center, middle point or the radius are too large.
SOLUTION Check the program.
1043 'The third axis of the plane cannot be the same as the first or the second one'
DETECTION During execution.
CAUSE Parameter 5 of function G20 (plane change) is the same as 1 or 2.
SOLUTION If the longitudinal axis of the tool (parameter 3) is the same as the first or second axis
of the plane (parameters 1 and 2), the third axis must be programmed with parameter
5. This parameter must not coincide with the first one or with the second one.
1044 'The first and second axis of the plane cannot be the same'
DETECTION During execution.
CAUSE In function G20 (plane change), the first (parameter 1) and the second (parameter
2) axes of the plane are the same axis.
SOLUTION Check the program.
1045 'The first axis of the plane has been programmed wrong'
DETECTION During execution.
CAUSE In function G20 (plane change) the first axis of the plane (parameter 1) is wrong.
SOLUTION The first axis of the plane must be one of the first three axes of the channel.
1046 'The second axis of the plane has been programmed wrong'
DETECTION During execution.
CAUSE Using function G20 (plane change) the second axis of the plane (parameter 2) is
wrong.
SOLUTION The second axis of the plane must be one of the first three axes of the channel.
1047 'A third axis is required for the plane (index 5) '
DETECTION During execution.
CAUSE In function G20 (plane change) the third axis of the plane is missing or is wrong.
SOLUTION If the longitudinal axis of the tool (parameter 3) is the same as the first or second axis
of the plane (parameters 1 and 2), the third axis must be programmed with parameter
5. The parameter must neither coincide with the first or with the second one and must
be one of the first three axes of the channel.
