0044 'Wrong axis name or undefined axis name'
DETECTION During the validation of the machine parameters.
CAUSE The machine parameter is not defined or it has the wrong axis name.
SOLUTION Correct the machine parameters. The valid axis names are the ones defined in
parameter AXISNAME.
In parameter AXISNAME, the axis name must be defined by 1 or 2 characters. The
first character must be one of the letters X - Y - Z - U - V - W - A - B - C. The second
character is optional and will be a numerical suffix between 1 and 9. This way, the
name of the spindles may be within the range X, X1…X9,...C, C1…C9.
0045 'Wrong spindle name'
DETECTION During the validation of the machine parameters.
CAUSE The user has defined the machine parameter with the wrong spindle name.
SOLUTION Correct the machine parameters. The valid spindle names are the ones defined in
parameter SPDLNAME.
In parameter SPDLNAME, the spindle name must be defined by 1 or 2 characters.
The first character must be the letter S. The second character is optional and will be
a numerical suffix between 1 and 9. This way, the name of the spindles may be within
the range S, S1 ... S9.
0046 'Nonexistent axis'
DETECTION During the validation of the machine parameters.
CAUSE The possible causes are:
• The user has assigned the name of an axis that does not exist to a machine
parameter.
• Either the VMOVAXIS or VCOMPAXIS axis is undefined in the basic volumetric
compensation.
SOLUTION Correct the machine parameters. The valid axis names are the ones defined in
parameter AXISNAME.
0047 'A main axis cannot be defined as slave'
DETECTION During the validation of the machine parameters.
CAUSE The slave axis of a gantry axis is the master of another gantry axis.
SOLUTION Correct the gantry axes table. The master axis of a gantry axis cannot be the slave
of another gantry axis.
0048 'An axis cannot be a slave of several masters'
DETECTION During the validation of the machine parameters.
CAUSE The slave axis of a gantry axis is already defined as the slave axis in another gantry
axis.
SOLUTION Correct the gantry axes table. An axis cannot be the slave of several masters.
0049 'A master axis cannot be a slave and vice versa'
DETECTION During the validation of the machine parameters.
CAUSE The master axis of a gantry axis is the slave of another gantry axis or vice versa.
SOLUTION Correct the gantry axes table. The master axis of a gantry axis cannot be the slave
of another gantry axis or vice versa.
0050 'The master and slave axes must be of the same type (AXISTYPE)'
DETECTION During the validation of the machine parameters.
CAUSE Both axes of a gantry pair are not of the same type; linear or rotary.
SOLUTION The axes of a gantry pair must be of the same type, linear or rotary (parameter
AXISTYPE). Check the gantry axes table and/or the AXISTYPE parameter of both
axes.
0051 'The master and slave axes must have certain parameters with the same value'
DETECTION During the validation of the machine parameters.
CAUSE The two axes of a gantry axis do not have the same properties.
SOLUTION Check the gantry axes table and/or the following machine parameters of the axes.
• The linear axes must have parameters AXISMODE, FACEAXIS and LONGAXIS
set the same way.
• The rotary axes must have parameters AXISMODE, SHORTESTWAY and
CAXIS set the same way.
