Error solving manual.
CNC 8060
CNC 8065
·9·
(REF: 1709)
0052 'Module difference too small'
DETECTION During the validation of the machine parameters.
CAUSE The difference between machine parameters MODUPLIM and MODLOWLIM is
lower than the resolution of the axis.
SOLUTION Check the resolution of the axis; if correct, increase MODUPLIM or decrease
MODLOWLIM.
0053 'Parameter MGPAXIS repeated in several handwheels'
DETECTION During the validation of the machine parameters.
CAUSE There are two or more handwheels assigned to the same axis in the Jog table
parameters.
SOLUTION One axis can only have one handwheel assigned to it.
0054 'The MOVAXIS and COMPAXIS axis must be different'
DETECTION During the validation of the machine parameters.
CAUSE In one of the cross compensation tables, the compensated axis and the axis whose
movement affects the compensated axis are the same.
SOLUTION The two axes of each cross compensation table must be different (parameters
MOVAXIS and COMPAXIS).
0055 'The same axis is causing and suffering the cross compensation error'
DETECTION During the validation of the machine parameters.
CAUSE In the cross compensation tables, checking the different associations of
compensated (affected) axes (parameter COMPAXIS) and those (parameter
MOVAXIS) whose movements affect the other ones, there is an axis whose
movement is affected by itself.
SOLUTION Check the relationship between the defined cross compensations. Check parameters
MOVAXIS and COMPAXIS of the defined cross compensations.
0056 'Compensation table positions not in ascending order'
DETECTION During the validation of the machine parameters.
CAUSE In the compensation tables, the points to be compensated are not ordered correctly
or the value to compensate in all the points have a zero value.
SOLUTION The POSITION parameter within the compensation tables must have ascending
values. The value to compensate cannot be zero in all the points.
0057 'Compensation table with error slope greater than 1'
DETECTION While validating the machine parameters (leadscrew error compensation table)
CAUSE In the leadscrew compensation tables, the difference between two consecutive errors
is greater than the gap between those points.
SOLUTION The error slope in leadscrew compensation tables cannot be greater than 1. Increase
the gap between points; if this is not possible, the error entered for the leadscrew is
so large that cannot be compensated for.
0058 'The CNC must be restarted too assume the changes in the HMI table,'
DETECTION During the validation of the machine parameters.
CAUSE The CNC application must be restarted in order to assume the changes made to the
HMI table.
SOLUTION Restart the CNC.
0059 'The CNC must be restarted too assume the changes in the tool magazine table,'
DETECTION During the validation of the machine parameters.
CAUSE The CNC application must be restarted in order to assume the changes made to the
tool magazine table.
SOLUTION Restart the CNC.
0060 'The maximum jogging feedrate exceeds the maximum feedrate set for the axis'
DETECTION During the validation of the machine parameters.
CAUSE Parameter MAXMANFEED is greater than G00FEED.
SOLUTION Decrease the value of parameter MAXMANFEED; it must be lower than G00FEED.
0061 'The manual rapid feedrate exceeds the maximum feedrate set for the axis'
DETECTION During the validation of the machine parameters.
CAUSE Parameter JOGRAPFEED is greater than G00FEED.
SOLUTION Decrease the value of parameter JOGRAPFEED; it must be lower than G00FEED.
