Fagor ADVANCE CONCEPT - Page 7

16/11/2012
7
SUPPLY
VOLTAGE
CABLE
SECTION
FUSE
RING FUSE
DIFFERENTIAL
DEVICE
400V 3N
50-60Hz
3x2.5 mm2 + N+T 20A 300mA
230 V 3N
50-60Hz
3x4 mm²+N+T 32A 300mA
TOTAL POWER kW 10.2
ACE-061 / AE-061 / APE-061
SUPPLY
VOLTAGE
CABLE
SECTION
FUSE
RING FUSE
DIFFERENTIAL
DEVICE
400V 3N
50-60Hz
3x6 mm2 + N+T 32A 300mA
230 V 3N
50-60Hz
3x10 mm²+N+T 63A 300mA
TOTAL POWER kW 19.2
ACE-101 / AE-101 / APE-101
SUPPLY
VOLTAGE
CABLE
SECTION
FUSE
RING FUSE
DIFFERENTIAL
DEVICE
400V 3N
50-60Hz
3x16 mm2 +N+T 80A 300mA
230 V 3N
50-60Hz
3x35 mm²+ T 125A 300mA
TOTAL POWER kW 38.4
ACE-201 / AE-201 / APE-201
SUPPLY
VOLTAGE
CABLE
SECTION
FUSE
RING FUSE
DIFFERENTIAL
DEVICE
400V 3N
50-60Hz
3x10 mm2 + N+T 63A 300mA
230 V 3N
50-60Hz
3x25 mm²+ T 100A 300mA
TOTAL POWER kW 31.2
ACE-102 / AE-102 / APE-102
SUPPLY
VOLTAGE
CABLE
SECTION
FUSE
RING FUSE
DIFFERENTIAL
DEVICE
400V 3N
50-60Hz
3x25 mm2 + N+T 125A 300mA
230 V 3N
50-60Hz
3x70 mm²+ T 180A 300mA
TOTAL POWER kW 62.4
ACE-202 / AE-202 / APE-202
