12 V DISPLAY (ACE and ACG) 12046671
12 V DISPLAY (ACE and ACG) 1204667112 V DISPLAY (ACE and ACG) 12046671
12 V DISPLAY (ACE and ACG) 12046671
⇒
⇒⇒
⇒ Chamber temperature selector
⇒
⇒⇒
⇒ Time / core temperature selector switch
⇒
⇒⇒
⇒ Chamber temperature display (Setting + True)
⇒
⇒⇒
⇒ Time / core temperature display (Setting + True)
⇒
⇒⇒
⇒ Buzzer
⇒
⇒⇒
⇒ BMF
⇒
⇒⇒
⇒ Interface with membrane keyboard
Buttons (ON, OFF, Mode, Function, Pow/spe., Humidifier, CD, Start, Stop)
Leds (Convection, Mixed, Steam, Pow1, Pow2, Pow3, CD, Spike, Delta)
NOTE:
NOTE: NOTE:
NOTE:
The card is supplied with software saved on it
No of version to be saved: 0.1
A label indicates the SAT reference (12046671) and the software version number: 0.1
DETAIL A
Indicated on label
REFERENCE: 12046671
VERSION NO. 0.1
