16/11/2012
5
ELECTRICAL CONNECTION
ELECTRICAL CONNECTIONELECTRICAL CONNECTION
ELECTRICAL CONNECTION
The electrical connection of the appliance must always be carried out by an OFFICIAL TECHNICAL SERVICE
OFFICIAL TECHNICAL SERVICE OFFICIAL TECHNICAL SERVICE
OFFICIAL TECHNICAL SERVICE or
an
AUTHORISED TECHNICAL SERVICE
AUTHORISED TECHNICAL SERVICEAUTHORISED TECHNICAL SERVICE
AUTHORISED TECHNICAL SERVICE.
The legal standards in force in each country on connections to the mains should be taken into account.
Check that the mains voltage corresponds to that indicated on the nameplate.
Use POLYCLOROPRENO
POLYCLOROPRENOPOLYCLOROPRENO
POLYCLOROPRENO cable sleeves or other similar materials (Ho5RN
Ho5RNHo5RN
Ho5RN-
--
-F
FF
F).
A switch device should be installed next to the appliance for all the phases, with a gap of a minimum of 3 mm
between contacts. This switch will be equipped with fuses.
The appliance must be earthed, from the connection strip of the appliance to the earth connection of the main
power supply.
The manufacturer will not be held liable for damage originated by failure to observe these requirements.
To access the connection strip, release the left side panel, pass the cable hose through the stuffing box on the
exterior base and conenct as shown on the strip.
The electrical cord must correspond to standard EN 60335-1:2002 “ordinary polychloroprene sheathed flexible
cable”.
The cord designation must be H05RN-F in accordance with CENELEC and 60245 IEC 57 in accordance with CEI.
IMPORTANT:
IMPORTANT:IMPORTANT:
IMPORTANT:
Before installing the left side panel, attach the electrical supply hose securely to the stuffing box.
When several appliances are installed in series, they should be earthed to each other using the point assigned
for this purpose (equipotent outlet), located at the base of the oven, at the back.
