Fagor CONCEPT ACE-201 - CORE PROBE SPIKE (OPTIONAL); Using the Optional Core Probe

ENGLISH CONCEPT USE AND MAINTENANCE MANUAL
24
CORE PROBE SPIKE (OPTIONAL):
Select by pressing button 17 and with the core probe display lit.
Selected temp.
Turn control 13 to select the required core
temperature.
Window 12 displays the selected core
temperature from 0 to 99ºC.
Window 11 displays the true temperature in
the core probe.
Turn control 10 to select the oven chamber
temperature.
Window 8 displays the selected oven
temperature.
Window 8 displays the true temperature in
the oven chamber.
When the core temperature reaches the
required temperature, the oven stops and
an alarm is heard.
True oven temp.
Oven temp
selection
Selected core
temp.
True core temp.
Core probe temp.
selection
Core probe function
display
