Fagor DDS AXD/SPD 2.50 User Manual

Drives
3.
180
Ref.1912
DDS
HARDWARE
· 102 ·
F. H3/11
Current derating on ·AXD|MMC 2.50· drives for fc = 4 kHz.
F. H3/12
Current derating on ·AXD|MMC 2.75· drives for fc = 4 kHz.
F. H3/13
Current derating on ·AXD|MMC 3.100· drives for fc = 4 kHz.
F. H3/14
Current derating on ·AXD|MMC 3.150· drives for fc = 4 kHz.
F. H3/15
Current derating on ·MMC 3.200· drives for fc = 4 kHz.
AXD|MMC 2.50
T ambient In Imax.
° C ° F A A
35 95 25.0 50.0
40 104 25.0 50.0
45 113 25.0 50.0
50 122 22.2 44.4
55 131 19.3 38.6
60 140 16.3 32.7
40
I (Arm s)
Tambient
°C (°F)
(104)
In
Im ax
10
0
35
(95)
45
(113)
50
(122)
55
(131)
60
(140)
20
30
40
50
35 40 55 60
40
I (Arms)
Tambient
°C (°F)
45 50
(95)
(104)
(113) (122) (131) (140)
50
In
60
Imax
70
30
20
AXD|MMC 2.75
T ambient In Imax.
° C ° F A A
35 95 37.5 75.0
40 104 37.5 75.0
45 113 37.5 75.0
50 122 32.2 64.4
55 131 26.6 53.3
60 140 20.7 41.3
35 40 55 60
40
I (Arms)
Tambient
°C (°F)
45 50
(95)
(104)
(113) (122) (131) (140)
60
In
80
Imax
20
100
AXD|MMC 3.100
T ambient In Imax.
° C ° F A A
35 95 50.0 100.0
40 104 50.0 100.0
45 113 50.0 100.0
50 122 45.8 91.7
55 131 41.3 82.7
60 140 36.7 73.3
35 40 55 60
60
I (Arms)
Tambient
°C (°F)
45 50
(95)
(104)
(113) (122) (131) (140)
80
In
100
Imax
40
120
140
160
AXD|MMC 3.150
T ambient In Imax.
° C ° F A A
35 95 75.0 150.0
40 104 75.0 150.0
45 113 75.0 150.0
50 122 70.6 141.3
55 131 65.6 131.3
60 140 60.5 121.0
AXD|MMC 3.200
T ambient In Imax.
° C ° F A A
35 95 90.0 180.0
40 104 90.0 180.0
45 113 90.0 180.0
50 122 84.3 168.7
55 131 78.0 156.1
60 140 71.5 143.1
35 40 55 60
100
I (Arms)
Tambient
°C (°F)
45 50
(95)
(104)
(113) (122) (131) (140)
In
150
50
200
Imax
