Fagor DDS AXD/SPD 2.50 User Manual

Installation
8.
Ref.1912
· 305 ·
DDS
HARDWARE
CAN connection with a FAGOR 8037 CNC
The CAN DRIVES connection of a FAGOR 8037 CNC will be made through
the CAN connector on the top rear of the CNC. See figure.
For further information, see the installation manual of the FAGOR 8037
CNC.
CAN connection with a FAGOR 8055i CNC
The CAN DRIVES connection of a FAGOR 8055i CNC to the drives will be
made through the CAN DRIVES connector on the top rear of the module.
See figure.
For further information, see the installation manual of the FAGOR 8055i
CNC.
F. H8/44
CAN DRIVES connector of the FAGOR 8037 CNC.
F. H8/45
CAN DRIVES connector of the FAGOR 8055i CNC.
CAN DRIVES
CAN DRIVES
8055i CNC
