Dimensions
DIMENSIONS
Modular drives
11.
Ref.1912
· 371 ·
DDS
HARDWARE
AXD/SPD/MMC 1.35
F. H11/12
Modular drives, AXD/SPD/MMC 1.35. Dimensions.
Dimensions in mm. 1 in = 25.4 mm
R3.5
8.5
22
R3.5
R6.5
8
7.5
77
266.5
255
389
347
373
45
