Dimensions
11.
DIMENSIONS
Modular drives
384
Ref.1912
DDS
HARDWARE
· 372 ·
AXD/SPD/MMC 2.50, AXD/SPD/MMC 2.75, SPD 2.85
F. H11/13
Modular drives, AXD/SPD/MMC 2.50 | 2.75, SPD 2.85. Dimensions.
Dimensions in mm. 1 in = 25.4 mm
R3.5
8.5
22
R3.5
R6.5
8
7.5
389
347
255
77
373
399
267
117
