Control point
Double hotplate sensors
Hotplate pilot light
Selected power display
Residual heat display
Power sensors
from 0 to 9
from 9 to 0
Blocking control point
Blocking sensor
ON/OFF sensor
55
VERTICAL CONTROL SENSORS
SENSOR DESCRIPTION
TYPE VT: MPDP-/ HPDP-/ MPGP-/ HPGP
VT7:FPDM-
