9. Circuit Diagrams
Circuit Diagram: Hob
ArtNo.095-0003 - Circuit diagram - 90 induction
ArtNo.080-0051 - 90 Elan induction (hob) circuit diagram
8 8
8 8
8
br
br
br
br
br
br
br
b
br
br
brbr brbr
w
r
2.3kW 2.3kW 2.3kW
1.4kW 1.4kW
CU1
CU2
CU3
A
C D F GE
B
br
br
br
br br
br
br
br
br br
w
r
w rv y
w r
v
y
v
y
b
br
bbr
yv
wr vy bbr
Code Description
A Touchlite panel
B Distribution board
C Left-hand front control
D Left-hand rear control
E Central control
F Right-hand rear control
G Right-hand front control
CU1 Left-hand pair (slave) control unit
CU2 Centre (slave) control unit
CU3 Right-hand pair (master) control unit
Colour Code
b Blue
br Brown
bk Black
or Orange
r Red
v Violet
w White
y Yellow
g/y Green/yellow
gr Grey
