Falcon 90 Induction - Technical Data; Connections, Dimensions, and Ratings; Oven Efficiency and Performance Data

36
10. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening.
Connections
Electric
230-240V 50Hz
Dimensions
Overall height minimum 905mm maximum 930mm
Overall width 900mm
Overall depth 602mm (to fascia inc. splashback); 610mm (over hotplate)
Refer to 'Positioning the Cooker'.
Ratings
ArtNo.313-0002 - 110 induction hob rating
1.4kW
1.4kW
2.3kW
2.3kW 2.3kW
Ovens
Main oven Tall oven
Forced air convection Forced air convection
2.5kW 2.5kW
Energy eciency class on a scale of A (more ecient) to G (less ecient) A A
Energy consumption based on standard load 0.85kWh 0.99kWh
Usable volume (litres) 67 66
Size Large Large
Time to cook standard load 38 minutes 49 minutes
Surface area of the grid 1400cm² 790cm
2
Grill 2.3 kW
Maximum total electrical load at 240V: 17.1kW (approximate total including oven lights, oven fan, etc.)
