GSM
I Falcon GSM Installation and Operation Manual
22
The Pima serial interface will send the standard FSK Contact ID
alarm codes.
DSC NEO SERIAL INTERFACE
Set the serial port format to DSC PowerSeries Neo on the Falcon
GSM (Refer to Section 3.4). The Falcon GSM can send alarms
received from the PC LINK_2 header of the DSC PowerSeries
Neo panel.
Plug the adapter marked DSC PowerSeries Neo into the PC
LINK_2 header on the alarm panel. Plug the other end into the
Falcon GSM’s serial port.
Proceed to program the panel as per the Falcon Connection &
App Set-up Guide provided, for alarm signals to be sent and/or
for app connectivity.
DSC POWERSERIES FSK KEY-BUS MODULE
The Falcon GSM can send alarms received from the keypad-bus
of the DSC PowerSeries alarm panel.
Wire the DSC PowerSeries FSK Key-bus Module to the keypad-
bus on the alarm panel and then connect the 4-pin molex
connector to the serial port of the Falcon GSM.
Proceed to program the panel as per the Falcon Connection &
App Set-up Guide provided, for alarm signals to be sent and/or
for app connectivity.
