Falcon GSM - Features & Functions; Reporting Options; Interfaces; Programming

2. FEATURES & FUNCTIONS
2.1 Reporting Options
§ Option for single or dual sim card operation for enhanced
network reliability
§ GPRS reporting to a control room
2.2 Interfaces
Ÿ 7 Hardwired inputs with positive trip, negative trip or both
Ÿ Dedicated AC Supply monitoring input
Ÿ 2 onboard relay outputs which can be controlled by GPRS
Ÿ Contact ID tip and ring telephone interface to leading control
panels
Ÿ Serial alarm interface to leading control panels
Ÿ Over-the-air panel uploading and downloading on the Rhino
and Texecom Premier control panels through the serial
interface
2.3 Programming
Ÿ Full programming and software updating via a computer serial
port
Ÿ Programming over-the-air via GPRS
2.4 Indicators and Controls
Ÿ Status and error indication via a seven segment display
Ÿ Serial port selection via the onboard push-button
I Falcon GSM Installation and Operation Manual
