To do so:
Ÿ Briefly press the push-button until the Falcon GSM swaps SIM
cards and restarts using the new SIM card
Ÿ Wait until the Falcon GSM has re-connected to the GSM
network on the new SIM card and displays the signal strength.
Ÿ If the Falcon GSM displays an error message (E1 or E4), the
selected SIM card is not working and the other one should be
selected
Ÿ The minimum signal strength required is 5. Lower than this
signal strength will make it difficult to access the Falcon GSM
remotely
3.5 Selecting the Alarm Panel Serial Port Format
The alarm panel serial port can be selected via the onboard
push-button (as well as the PC-based programming software).
The following serial port formats are available:
Ÿ Rhino 816 and Rhino 68 alarm panels
Ÿ Texecom premier range (panel uploads and downloads can
also be done)
Ÿ Paradox SP & MG Series
Ÿ Pima
Ÿ IDS
Ÿ DSC Neo Series
Ÿ Sherlotronics MB4000
Ÿ DSC PowerSeries
I Falcon GSM Installation and Operation Manual
