Falcon T Series Service Manual

30
T-Series Service Manual
Trim Assemblies
T351
Closet Lock
B
AA
Y
E
X
H
H
K
CC
Z
N
M
BB
MM
W
NN
Note: Spring Cage components require lubrication. See page 47 for specifications.
Call Out
Number Description Part Number
Call Out
Number Description Part Number
B Open Lever, Outside See Page 46,47 Y Turn Knob, Knurled 030738-000*
E Lever Set Screw 030831-004-30 Z Turn Knob and Set Screw
Assembly
A30788-000*
H Rose 030706-002* AA 6-Pin Cylinder A23161-05*
K Mounting Post (2) 030715-000-30 BB Spring Cage and Spindle,
Outside, 6-Pin Cylinder
A30910-060-00
M Deadlatch A98535-00D* CC Spindle, Outside, 6-Pin Cylinder A30905-060-00
N
#8-32 x 6M” Combo Screw
024416-012* MM Locking Spring Cage Q330-270
W Spring Cage and Spindle, Inside,
T351
A30776-001-00 NN Non-Locking Spring Cage Q330-271
X Spindle, Inside, T351 030703-001-30
*= Finish or Specify Finish on All
