FALEX 400 - Default Chapter; Table of Contents

1
Table of Contents
Page
Forward Instructions–How to Use This Manual ......................3
Safety, Safety Label Descriptions and Hazardous Areas
of Test Machine .........................................3
Section 1 General Information ....................................5
1.1 Technical Specications ..................................5
1.2 Brief Description of Equipment .............................5
1.3 Packing List ............................................6
1.4 Getting To Know The Falex 400 ............................10
Section 2 Setup ................................................15
2.1 Initial Setup ...........................................15
2.2 Sample Area and Fuel Preparation .........................15
2.3 Instrument and Test Conguration ..........................17
Section 3 Software Operation ....................................22
3.1 Falex 400 Software Program ..............................22
3.2 Run Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3 Data .................................................28
Section 4 Disassembly and Component Cleaning ...................30
4.1 Heater Tube Disassembly ................................30
4.2 Continued Unit Disassembly Cleaning ......................31
4.3 Component Cleaning ....................................31
Section 5 Software Preferences ..................................32
Section 6 Maintenance ..........................................34
6.1 Charcoal Filter Replacement ..............................34
6.2 Desiccant Cartridge Replacement ..........................34
6.3 Pump Maintenance (Prime, Purge) .........................36
Section 7 Calibration ...........................................39
7.1 Thermocouple ....................................39
7.2 Differential Pressure ...............................40
7.3 System Pressure ..................................41
7.4 Factors .........................................41
