45
Description Alarm Abort Condition Lo Limit Hi Limit Alarm Message (HMI) Comments
Bus Bar Temp Thermo- couple Failure
x Test active -100 ºC
Bus Bar Thermocouple Failure
Abort after 1 second. Possible Cause: Thermocouple failure, Thermocouple not con- nected.
Sample Fuel Temp Ther- mocouple Failure
x Test active -100 ºC
Sample Thermocouple Failure
Abort after 1 second. Possible Cause: Thermocouple failure, Thermocouple not con- nected.
Safety Cover Missing x Test active Bus Bar Cover Missing
Warning only. Possible Cause: Cover removed during test, photo eye failure.
Data Transfer Failure x
Data xfer button selected
FTP Comm Open Action Failure
Checked after data transfer but- ton selected. Possible Cause: Data file not created, data directory does not exist, FTP application corrupt.
Section 8: Service
