162236M User Manual GSM Gateway Page 4 of 20
CONNECTIONS
Insert the SIM card, connect the Antenna, the lift phone Fältcom ECII Flex and Power
SIM
Lift phone Fältcom ECII Flex
in LIFT CAR
TELE
PHONE
ANT
Power
Supply
12-24 VDC
230 VAC
OR
Battery
ANTENNA
SIM PIN code
Activated or deactivated PIN code
OR
ACTIVATED
Set PIN
code to:
1234
SIM
DEACTIVATED
Turn of
PIN code
lock
SIM
1
2
3
4
…
GSM Gateway
