4
Use either the pre-installed 1.5 mm or 2.5 mm edge protectors (C) (including adhesive) when using the
pedals on a oor.
Quick Guide
• 1x CSL Pedals (2x Edge Protector 1.5 mm pre-installed)
• 2x Hard Mount Spacer
• 2x Edge Protector 2.5 mm (Adhesive Included)
• 8x M4x12 mm Countersunk Mounting Bolts
• 1x RJ12 Cable
• 1x T20 Torx Key
A
B
C
D
E
F
For compatibility information, visit the product
page on Fanatec.com.
Hard-mount using all four mounting holes (bolts are not included).
Download drilling template from the product page on Fanatec.com.
3A
2D
3B
4C
4B
4A
M6x(22+X) mm
Port only for Wheel Base or CSL Pedals Load Cell Kit.
ATTENTION!: Connecting any other pedal or peripheral to this port may cause permanent damage!
CSL Pedals Clutch Kit (Sold Separately).
Connect the brake pedal lever unit cable to the “Brake” port.
PACKAGE CONTENTS
1
CONNECTIONS
4
HARD
-
MOUNTING
3
PEDAL ADJUSTMENT
2
Update your wheel base rmware. You can obtain the latest driver from fanatec.com/downloads. Follow the
instructions provided by the Driver & Firmware Instruction Manual which can be found on the product page.
NOTE: In order to update the rmware of this product, a PC is mandatory and PC mode must be active on the
wheel base.
ATTENTION
5
Our Support Team is ready to help you! Visit
fanatec.com/support/faq for assistance.
SUPPORT
VIDEO
6
7
Watch our CSL Pedals video guide:
Fanatec.com/QR/CSL-P
Download our app:
Fanatec.com/app
This product is under warranty of Endor AG. Refer to the included warranty sheets as well as the terms & conditions
of Endor AG on Fanatec.com.
