Explanation control functions
10
Determining the ventilation position
The control computer determines the use of air inlets, extra inlets and fans based on the combi-table. The
example below shows a combi-table with modulating fans. The relay fans will do 20.000 m3 each.
Ventilation
Exhaust
Inlets
Position
MOD
Extra fans
Relay (0-1-M)
Cap.
Inlet
Extra
Pres-
sure
%
%
1
2
3
4
5
m3/h
%
%
Pa
M1
1
1
M
0
0
0
0
200
1
0
0
M2
20
100
M
0
0
0
0
20000
20
0
0
M3
21
50
M
M
0
0
0
21000
21
0
0
M4
39
99
M
M
0
0
0
39000
39
0
0
M5
40
100
1
1
0
0
0
40000
40
0
0
M6
60
100
1
1
1
0
0
60000
50
0
0
M7
75
100
1
1
1
1
0
80000
75
0
0
M8
100
100
1
1
1
1
1
100000
100
0
0
The ventilation level is expressed as a percentage. The control computer uses this percentage to find the required
ventilation settings in the combi-table. The control computer determines the ventilation % between two positions,
and controls the modulating fans using this.
Example: Taking ventilation positions from the combi-table
Required ventilation level: 30%. This value is precisely between positions M3 and M4.
The control computer uses the following fans:
 Both fans are controlled on for 75% of the set cycle time (midway between M3 and M4). If the
ventilation level increases further, so will the modulation percentage.
 Air inlet control depends on the settings. The control computer can open the air inlets 30% (midway
between positions M3 and M4). The inlet position can also be modulated between 21% and 39%.
The control computer controls ventilation with fans (exhaust) and air inlets. The control computer takes the
positions from the combi-table. The combination of exhaust and inlet positions creates a certain under pressure in
the house. The required under pressure is in the combi-table. The control computer can influence position of the
air inlets and accurately control the pressure. (Optimization).
