Connection Schematic Diagram
Type-C Transmission
Monitor Introduction
3.5mm
Earphone
HDMI Transmission
Attention:
Please select the right annunciator or port for your devices, and connect in the right way.
You may restart the phone or computer when it is out of order.
DCIN Type-CUSB 1
HDMI
OK
+
DCIN Type-CUSB 1
HDMI
USB 2
OK
+
USB connection
for keyboard mouse,
or U disk ect
