FG7X Housing Instruction Manual 20150101
Installing the Fantasea Hand Strap (Cat. No. 11188) on the Housing
1. Pull the narrow nylon Velcro strip through top of lower housing ring (below the locking latch) in a
downward direction to the end of the strip (images #20 and 21).
2. Place the wide flat Velcro mid-section over the locking latch and pull the thin Velcro strip over the
top of this mid-section and through the upper
housing ring from bottom to top all the way through
(image #22).
3. Double back the thin nylon Velcro strip and secure it
tight to the top of the Velcro strip previously
inserted (same strip) and press down. Then cover
with the wide flap (should be on the right side) over
the thin Velcro strips (image #23).
4. Place top flap (with logo) over bottom flap and press
to close (images #24 below and #25 on the following page).
