52
Wireless Access (AP+Client) Option
• SSID: Type-in the SSID name or click on the “Rescan” button for
automatic search for available wireless networks.
• Password: Type-in the correct password to join the wireless network.
• IP Address: Select either DHCP or Manually assign an IP address
o By selecting DHCP, the host will provide an automatic IP address to
connect to the internet.
o By selecting Manual, you have to manually assign an IP address to
connect to the internet.
Wired Access Option
By selecting the Wired option, the Dynamic IP is selected as the default setting. You can
manually assign your own IP address by clicking on the green arrow and select the Static
IP option.
8.3.4. Services
Windows sharing and network services are available to access the WiFi HDD
8.3.4.1. Windows Sharing Services
Data sharing and accessing the WiFi HD product makes it simple by enabling the
Windows File Services. By default, this feature is already enabled as seen on the
screenshot below.
