43
Parts list • Liste des composantes
SHR8004
4
1
3
2
8
9
7
5
6
BOM # Description SHR8004
(40443-1)
1 Motor Assy, R2E 250-AW-57 411728
2 Electrostatic Filters Kit 11.5” x 15” 40482
3 Heat Recovery Cell 12” x 12” x 15” 402064 x2
4 Kit Drain Plug 40315 x2
Drain, T 410788
5 PCB, RV-CTRL 422677
6 Rocker Switch 410213
7 Kit,Repl,HCE3.0,RV-CTRL 427704
8 Capacitors 25uF 411618
9 Auto-Transformer 412437
Temperature Probe 40286
Fuse (8 Amps) 410432
MERV6 Filters 40458
