1.SAFETY PRECAUTIONS SAFETY B-82604EN/01
-s-6-
扉が開いたときに作動するリミットスイッチ
防護柵
パネルボード
EAS1
EAS11
EAS2
EAS21
（注） EAS1,EAS11, EAS2,EAS21は操作パネル上のプリン
ト板の端子台上に出されています。
詳細はR-J3iC制御部保守説明書をご参照下さい。
Safety fence
Limit switch which operates when the gate is
opened.
Panel board
Note) Terminals EAS1, 11 and EAS2, 21 are on the
PC board on the operator’s panel.
Refer to the R-30iA CONTROLLE
R
MAINTENANCE MANUAL.
Fig.1.1(b) Safety Fence and Safety (For R-30iA CONTROLLER)

FANUC R-J3iB Specifications

General

Operating System	FANUC proprietary OS
Communication Ports	RS-232, Ethernet
Axes Control	Up to 8 axes
Programming Language	FANUC Karel, TPE
Power Supply	200-230V AC, 50/60 Hz
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Teach Pendant	FANUC Teach Pendant (A05B-2255-C100)
