Fanvil i16V User Manual

49
Door Lock Control
Door Lock
Execute a door lock to open or close the door
Action
Door Open/Close
Open mode
Once: perform door opening action, and will be closed automatically
when timeout.
Continue: perform the door opening action, the door will not be closed
automatically and need to closed manually when timeout.
Auto Open Setting
SIP Register
Fail
When the SIP line registration fails, the door lock could be set to open
automatically after the timeout period.
Line
The Line could select line 1 / line 2 / all
Door Lock
The door lock could select lock 1 / lock 2 / all lock
Waiting Time
The door will be opened automatically when timeout. (unit: second)
Network
Connect Fail
When the network connection fails, the door lock could be set to be
opened automatically after the timeout period.
Door Lock
The door lock could select lock 1 / lock 2 / all lock
Waiting Time
Timeout time automatically opens the door, unit s
9.26 Alert &Security Settings

Fanvil i16V Specifications

General

Color	Yes
Relay inputs	2
Speakerphone	-
Video codecs	H.264
Certification	CE/FCC
Number of buttons	1 buttons
Connectivity technology	Wired
IK code	IK10
Product color	Stainless steel
International Protection (IP) code	IP65
Display diagonal	- \
Megapixel	2 MP
Maximum frame rate	25 fps
Optical sensor size	1/2.7 \
Minimum illumination	0.1 lx
Viewing angle, vertical	84 °
Maximum video resolution	1280 x 720 pixels
Viewing angle, horizontal	112 °
Networking standards	IEEE 802.1x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, LLDP, PPPoE, 802.1x, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069
Outdoor unit power type	DC
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	165 mm
Package width	260 mm
Package height	62 mm

Weight and Dimensions

Depth	120 mm
Width	195 mm
Height	34 mm
Weight	1015 g
