Active Mode : When the electric-lock starting current is less than 12V/500mA, can use the internal
drive mode, the electric lock interface is 12V DC output.
3) Wiring instructions:
Driving Mode Electric-lock Mode
Active Passive
No electricity
when open
Electrify
when open
√
√
√
√√
√
JP1
Jumper
Connections
3
NO: Normally Open Contact
COM: Common Contact
NC: Normally Close Contact
√ √
