- 16 -
Mi 2513/2
- Delete <n°> “user name”? With arrows or select
<YES> or <NO> and then press ; choosing <NO> you
will return to the selection of the user to be deleted, choosing
<YES> LCD will briey show “saved” to indicate that the op-
eration has been done and the system moves back to the list
of the users to be deleted. Press to return to the previous
menu.
Delete all
It is possible to delete, with a single operation, all the users from
the directory; the command doesn’t affect the other settings of
the system. Pressing key you access the menu “Delete all”
(if no user is stored in the directory, the system doesn’t allow
you to access this menu), whilst pressing you will return to
the previous menu.
Accessing the menu “Delete all”, the rst line of LCD shows:
- Delete all? With arrows or select <YES> or <NO> and
then press ; choosing <NO> you will return to the menu
“Delete all”, choosing <YES> all the users will be erased, the
directory will be blanked and then the system returns to the
menu “Delete all”. Press key to return to the previous menu.
Warning: this operation will erase all the users from the
directory. In case of unwanted action it is possible to recovery
erased data, if meanwhile no new users have been stored, with
the function “Recovery all” described in the next paragraph.
Recovery all
It is possible to recovery all the users just erased from the direc-
tory; pressing key you access the menu “Recovery all”,
whilst pressing key you will return to the previous menu.
Accessing the menu “Recovery all”, the rst line of LCD shows:
- Recovery all? With arrows or select <YES> or <NO>
and then press ; choosing <NO> you will return to the menu
“Recovery all”, choosing <YES> all the users, just erased from
the directory, will be recovered, directory will be restored and
then the system returns to the menu “Recovery all”. Press
to return to the previous menu.
Warning: this function can be executed at any time, but it
is necessary to pay attention that, if some new users have been
stored, from the time the directory has been erased and when
the function “recovery all” is executed, old data will not be recov-
ered completely.
Download
By pressing key the rst line of LCD will show: “Download”
and the device is ready to receive a conguration le from the
USB port. For details see paragraph “USB Connection”.
Upload
By pressing key the rst line of LCD will show: “Upload”
and the device is ready to send a conguration le to the USB
port. For details see paragraph “USB Connection”.
Format memory
By launching this function the device memory will be completely
blanked.
Warning: device memory will be completely blanked and,
after this operation, no data will be recoverable. Before launch-
ing "Format memory" evaluate carefully if really this is the action
you need.
Pressing key you access the menu “Format memory”
whilst with key you return to the previous menu. Accessing
the function “Format memory” the rst line of LCD will shows:
Format memory? With arrows or select <YES> or
<NO> and then press ; choosing <NO> you will return to the
menu “Format memory”, choosing <YES> a memory blanking
procedure will start, at the end the system returns to the menu
“Format memory”. Press to return to the previous menu.
System
In this section, system parameters can be programmed, pressing
the key you access the parameter to be programmed, while
pressing the key you return to the previous menu. Parame-
ters that can be programmed are:
- Addresses
- Timings
- Administrator Password
With or arrows you can select the parameter to be set,
while the key backwards you to the previous menu.
Addresses
Addresses of the devices driven by the external door station,
except the addresses of the users which must be programmed
in the proper section of the menu. Pressing you enter the
menu "Programming of addresses", while pressing you
return to the previous menu. Addresses to be set are:
- Door station address
- Digital exchanger address (PDX)
- Address of PB key, (PB-PB)
- Address of the auxiliary relay
- Video OFF -1- Start
- Video OFF -1- End
- Video OFF -2- Start
- Video OFF -2- End
- AUX TLC 1÷8
- Main AUX TLC
With or arrows select the requested parameter and con-
rm with the key. key will backwards you to the previous
menu.
Door station address
By pressing you enter the programming of the door sta-
tion address, whilst with key you return to the previous
menu. Entering the menu, the rst line of LCD shows “Enter
address”, whilst at the end of the second line the currently
stored value is reported (231 from factory). With erase the
old number, and with the keypad, enter the new one (from 231
to 240), then conrm by pressing , system returns to the
previous menu.
Digital exchanger address (PDX)
By pressing you enter the programming of the digital ex-
changer address, whilst with key you return to the previous
menu. Entering the menu, the rst line of LCD shows “Enter
address”, whilst at the end of the second line the currently
stored value is reported (no address from factory). With
key erase the old address, if present, and, with the keypad, en-
ter 201, if the door station has to call a main digital exchang-
er, or 210, if it has to call a secondary digital exchanger,
then conrm by pressing , system returns to the previous
menu.
Address of PB key (PB-PB)
Push-button PB (terminals PB-PB) can be used to call directly
a user of the system, instead of operate as "door lock release".
In this case it is necessary to program the address of the user
to be called. By pressing you enter the programming, whilst
with key you return to the previous menu. LCD shows “En-
ter block address” and on the bottom of the second line, the
address currently stored is reported (no address from factory).
With key erase the old address, if present, and enter the
new one, then conrm by pressing , display will show “En-
terat address” and on the bottom of the second line, the
currently stored value is reported (no address from factory).
With key erase the old at address, if present, and enter
the new one, then conrm by pressing , system returns to
the previous menu.
Attention: if button PB-PB is programmed to send a call,
it can’t be used to release the door lock. Any number stored
