- 17 -
Mi 2513/2
in this parameter sets the PB-PB button to send a call,
consequently, if you wish to use PB-PB button to release
the door lock, do not program any value in it.
Address of the auxiliary relay
An actuator address (211-230) or a user address (001-200)
can be linked to the auxiliary relay. Depending on the linked
address, the auxiliary relay operates in a different ways.
- Actuator address. Storing an actuator address, that is a
block address between 00 e 99 and a device address be-
tween 211 e 230, the auxiliary relay operates as an actuator
and, when called, it moves its contacts (C-NC-NO) accord-
ing to the operating mode set in “System” → “timings” →
“relay”.
- User address. Storing a user address, that is a block ad-
dress between 00 e 99 and a device address between
001 e 200, the auxiliary relays operates its contacts (C-NC-
NO) only when a “lock release” command arrives from a user
with address equal or higher to that stored in the device; if
address 00-000 is stored, the auxiliary relay will be activated
by the “door release” command sent by any user. Operating
mode of its contacts is set in “System” → “timings” →
“relay”.
To program the address select "Relay address" and press
. LCD shows “Enter block address”, while on the bottom
of the second line the address currently stored is reported (no
address from factory). With the key erase the old address,
if present, and enter the new one, then conrm by pressing
, display will show “Enterataddress” whilst, on the bot-
tom of the second line, the currently stored value is reported
(no address from factory). With the key erase the old at
address, if present, and enter the new one, then conrm by
pressing the key, system returns to the previous menu.
Attention: to identify the users with address equal or
higher to that stored, both block and at address must be con-
sidered (for example user 03-123, has an higher address with
respect to the user 02-200).
Storing 00-000, all the users of the system, by pressing the
“open door” button, will activate the auxiliary relay instead of
operating the door release circuit.
Video OFF -1- Start (TD2000-TD2000R)
In this parameter has to be stored the starting (lower) address
of the rst group of users which do not have to receive the
video signal (for example users with only audio intercom).
By pressing the key you enter the programming mode.
LCD shows “Enter block address”, while on the bottom of
the second line the address currently stored is reported (no
address from factory). With the key erase the old address,
if present, and enter the new one, then conrm by pressing the
key, display will show “Enterataddress” whilst, on the
bottom of the second line, the currently stored value is report-
ed (no address from factory). With the key erase the old
at address, if present, and enter the new one, then conrm by
pressing , system returns to the previous menu.
Video OFF -1- End (TD2000-TD2000R)
In this parameter has to be stored the ending (higher) address
of the rst group of users which do not have to receive the
video signal (for example users with only audio intercom).
By pressing the key you enter the programming mode.
LCD shows “Enter block address”, while on the bottom of
the second line the address currently stored is reported (no
address from factory). With the key erase the old address,
if present, and enter the new one, then conrm by pressing the
key, display will show “Enterataddress”whilst, on the
bottom of the second line, the currently stored value is report-
ed (no address from factory). With the key erase the old
at address, if present, and enter the new one, then conrm by
pressing the , system returns to the previous menu.
Video OFF -2- Start (TD2000-TD2000R)
In this parameter has to be stored the starting (lower) address
of the second group of users which do not have to receive the
video signal (for example users with only audio intercom).
By pressing the key you enter the programming mode.
LCD shows “Enter block address”, while on the bottom of
the second line the address currently stored is reported (no
address from factory). With the key erase the old address,
if present, and enter the new one, then conrm by pressing
, display will show “Enterataddress” whilst, on the bot-
tom of the second line, the currently stored value is reported
(no address from factory). With the key erase the old at
address, if present, and enter the new one, then conrm by
pressing system returns to the previous menu.
Video OFF -2- End (TD2000-TD2000R)
In this parameter has to be stored the ending (higher) address
of the second group of users which do not have to receive the
video signal (for example users with only audio intercom).
By pressing the key you enter the programming mode.
LCD shows “Enter block address”, while on the bottom of
the second line the address currently stored is reported (no
address from factory). With the key erase the old address,
if present, and enter the new one, then conrm by pressing
, display will show “Enterataddress”whilst, on the bot-
tom of the second line, the currently stored value is reported
(no address from factory). With the key erase the old at
address, if present, and enter the new one, then conrm by
pressing system returns to the previous menu.
AUX TLC 1÷8
Push-button panels TD2000 can drive external video modulators
(type VM2521) to which up to eight additional cameras can be
connected, for details see "External Video Modulators (PDX1)"
section. In the case of additional cameras, the addresses of the
additional cameras present in the installation and, if necessary,
the address of the main video camera (Main AUX TLC) must
be programmed.
To program the address of the rst additional camera select
from the menu "AUX TLC1" and press button to conrm,
display will show “Enter address” and on the bottom of the
second line, the currently stored value is reported (no address
from factory). With key erase the old address, if present,
and enter the new one, then conrm by pressing , system
returns to the previous menu.
If required, proceed in the same way programming the addresses
of the other additional cameras from AUX TLC 2 to AUX TLC
8 otherwise continue with other programmings.
Main AUX TLC
The main camera is the camera from which the audio-video
module starts the cyclic scan of the additional cameras.
To program the address of the rst main camera select from
the menu "Main AUX TLC" and press button to conrm,
display will show “Enter address” and on the bottom of the
second line, the currently stored value is reported (no address
from factory). With key erase the old address, if present,
and enter the new one, then conrm by pressing , system
returns to the previous menu.
