Parts Identification - RT17, RT19 Tedder
48
ITEM PART NUMBER DESCRIPTION
14 R3120102 CIR CLIP D.35
15 R3010294 HH SCREW M8X20
16 R3030802 WASHER M12 S.E.
17 R12061035 SPACER 54X45X8
18 R3120101 CIR CLIP Ø30
19 R3110003 TAB 8X7X40
20 R3010228 HH SCREW M12X30
21 R3030800 WASHER M12 S.E.
22 R18033491 PIN Ø30 L.119
23 R3090101 GREASE ZERK M8X1
24 R3011268 HH SCREW M12X120 ZN
25 R8010303 BEVEL PINION FOR ROTOR
26 R18033601 COMPLETE DRAFT SUPPORT
27 R1015252 CENTRAL CLOSING HOUSING
28 R3010250 HH SCREW M8X16
29 R3020302 NUT M8
30 R3010780 HH SCREW M8X30 ZN
31 R3020209 SELF LOCKING NUT M8
32 R18033544 PLATE
33 R18033777 SHAFT TRANSMISSION L.1560 MM - RT17
R12010211 SHAFT TRANSMISSION L.1783 MM - RT19
34 R3110002 TAB 8X7X35
35 R3110008 TAB 8X7X30
36 R18034226 CENTRAL PIN WITH BRACKET
37 R3010605 SCREW TCEI M12X55
38 R12240109 BEARING 6207
39 R18031169 or R8010317 BEVEL CROWN FOR ROTOR
40 R18031171 or R2010422 SAFETY LOOP
41 R12240160 BEARING 32007A
42 R18033532 PROTECTION SCREEN
43 R18031170 ARM CONNECTION FLANGE
44 R10011315 NILOS RING 32007 AV
45 R18032308 BUSH Ø54 L.106
46 R3080141 ELASTIC PIN 10X55
47 R3080142 ELASTIC PIN 6X55
48 R12240108 BEARING 6206 2RS
49 R12070330 SPACER 42X8X74
50 R8010304 CROWN FOR CENTRAL BOX
51 R18030620 ARM - RT17
R18032339 ARM - RT19
52 R3011297 SCREW TE M12X45 ZN.
