Farnell E30 - Introduction; Specification

an
E3o
laboratory
bench
POweE
nsh
button
switch.
current ranges, selected by means
E30/1 provides a stabilised d.c. voltage variable O to 30 volts at
O.5 amps or o to 15 volts at l amp whereas model E30/2 provides 0 to
30 volts at 1 amp or 0 to 15 volts, 2 amps. The ET30/2 is a twin
version of the E30/2
INTRODUCTION
A push button switch selects the required meter scale to display
either voltage or current. A similar push button switches mains
input to the unit on or off. Coarse and fine potentiometers provide
precise control over the continuously variable output.
The units are protected against progressive and sudden overloads by
electronic current liniting preset at approximately l10% of the max
imum current on the range emploved. In operation this circuit limits
the current that may e drawn from the unit. T7ith progressive over
loadthe voltage output falls vhile the current remains approximately
constant. On removal of overload the output vill reset to its
STABLLISED POWEA sUPPLY
FARNELI
The E30 power supplies will operate from mains supplies of 220V or
240V a.c. 50/6OHz in ambient temperatures of up to 45°C.
COARSE
VOLTAGE
OuTPUT
offers a choice of voltage and
E30/4
AMBS
Model
FINE
Model
E30/2 is
similar
with
appropriate range
markinqs
MAINS INPUT
OUTPUT E30/l
E30/2
ET30/2
LINE REGULATION
Output change for a +10%
mains change
LOAD REGULATION
Output change for a zero to
full load change
RIPPLE AND NOISE CONTENT
at full load (A£ = 80kHz)
OUTPUT IMPEDANCE, typical
TRANSIENT REcOVERY TIME,
typical
TEMPERATURE COEFFICIENT,
typical
OPERATING TEMPERATURE RANGE
STORAGE TEMPERATURE RANGE
PROTECTION
OVERALL DIMENSIONS approx.
WEIGHT apprOX.
SPECIFICATION
110, 220 or 240V a.c. ±l0%, 50/6OHz
O-30V,
0.5A or
0-l5v, lA
selected
by
switch
O-30V,
lA
or
0-15V,
2A
selected
by
switch
2 x
O-30V,
lA
or
O-15V, 2A
selected
by
switch.
Less
than
O.02%
or
2mV
whichever is
greater
Less
than
O.03%
or
3mV
whichever is
greater
Less than lmV r.m.s.
0.042 at 10kHz
Less than 20us for output to recover within
5OmV following a zero to full load change of
lus risetime
O.02% per "c
0 to 45c
-20c to +50°c
Constant current limiting preset to approx.
110% of maximum output current. Fuses for mains
input and d.c. output
E30/1 and E30/2
Height
Width
Depth
3.4 kg
187 mm
l06 mm
221 mm
(7% lbs)
(74")
(4%")
(84")
ET30/2
181 mm (7.13")
214 mm (8.43")
240 mm (9.45" )
6.2 kg (13.64 lbs)
3
origina voltage.
