shunt R10 in the O-15V mode, increasing the bias on VT4 base and
allowing the voltage across Rl6, (and therefore the current through
it) to rise to a higher value before vT4 is turned on.
Metering
A one milli amp f.s.d. meter is used to monitor the output voltage or
current. SW3 in the volts position connects the meter in series
with Rl3 and T5, (between positive and negative output terminals).
T5 is set to give f.s.d. on the meter at 3O volts. With SW3 in the
current position the meter (with T4 in series) senses the voltage
across Rl6. T4 is set to give f.s.d. on the meter with an output
current of 1 amp on model E3O/l and 2 amps on mode ls E30/2 and ET30/2.
