Type Signal Cable Encoder Cable Motor Cable Power Cable
Parameter
Setting Cable
Length supplied - 30cm 30cm - -
Max. Length 20m 20m 20m 2m 3m
23.1 Options
① Signal Cable
Item Length [m] Remark
CSM3-S-□ □ □F
CSM3-S-□ □ □M
□ □ □
□ □ □
Normal Cable
Robot Cable
□ is for Cable Length. The unit is 1m and Max. 20m length.
② Encoder Extension Cable
Item Length [m] Remark
CSVI-E-□ □ □F
CSVI-E-□ □ □M
□ □ □
□ □ □
Normal Cable
Robot Cable
□ is for Cable Length. The unit is 1m and Max. 20m length.
Manufacturer : MOLEX
Housing : 501646-1000
Terminal : 501648-1000
JST : Manufacturer
SMP-09V-NC : Housing
SHF-001T-0.8BS : Terminal
④
①
②
③
⑤
Manufacturer : MOLEX
Housing : 501646-2000
Terminal : 501648-1000
23. System Configuration [S-SERVOII MINI series]
