3. S-SERVOⅡ Part Numbering 4. Standard Combination
※ S-SERVOⅡ 2X, S-SERVOⅡ 3X product needs 2 or 3 sets of motors
for one drive. Combination of drive and motors can be diversifed so
please contact with sales division or distributor of FASTECH before
purchasing product.
S-SERVOⅡ-ST-56L- F-BK-PN05-□
Product Name
Brake
User Code
Encoder Resolution
S : Small
M : Medium
L : Large
XL : Extra Large
20 : 20mm
28 : 28mm
35 : 35mm
42 : 42mm
56 : 56mm
60 : 60mm
Motor Flange Size
ST : Stand Alone
MI : MINI Type
2X : 2 axes
3X : 3 axes
Drive Series Type
Motor Length
Blank : Without Brake
BK : Brake
F : 4,000[ppr]
Unit Part
Number
Motor Model
Number
Drive Model
Number
S-SERVOⅡ-ST-20M-F SM-20M-F SV2-PD-20M-F
S-SERVOⅡ-ST-20L-F SM-20L-F SV2-PD-20L-F
S-SERVOⅡ-ST-28S-F SM-28S-F SV2-PD-28S-F
S-SERVOⅡ-ST-28M-F SM-28M-F SV2-PD-28M-F
S-SERVOⅡ-ST-28L-F SM-28L-F SV2-PD-28L-F
S-SERVOⅡ-ST-35M-F SM-35M-F SV2-PD-35M-F
S-SERVOⅡ-ST-35L-F SM-35L-F SV2-PD-35L-F
S-SERVOⅡ-ST-42S-F SM-42S-F SV2-PD-42S-F
S-SERVOⅡ-ST-42M-F SM-42M-F SV2-PD-42M-F
S-SERVOⅡ-ST-42L-F SM-42L-F SV2-PD-42L-F
S-SERVOⅡ-ST-42XL-F SM-42XL-F SV2-PD-42XL-F
S-SERVOⅡ-ST-56S-F SM-56S-F SV2-PD-56S-F
S-SERVOⅡ-ST-56M-F SM-56M-F SV2-PD-56M-F
S-SERVOⅡ-ST-56L-F SM-56L-F SV2-PD-56L-F
S-SERVOⅡ-ST-60S-F SM-60S-F SV2-PD-60S-F
S-SERVOⅡ-ST-60M-F SM-60M-F SV2-PD-60M-F
S-SERVOⅡ-ST-60L-F SM-60L-F SV2-PD-60L-F
◆ S-SERVOⅡ ST series
Reduction Gear Ratio
Blank - Without Gear
PN03 - 1:3
PN05 - 1:5
PN08 - 1:8
PN10
- 1:10
PN15 - 1:15
PN25 - 1:25
PN40
- 1:40
PN50
- 1:50
