Process Controllers
FAST Lit. Part No. 229-51317 Rev. B (EMPLOYEE) 11/01/2007 (L20-321 rev 0 12/07) Page 8
© 2005-2007 Food Automation – Service Techniques, Inc. All Rights Reserved
This document contains confidential information. The dissemination, publication,
copying, or duplication of this document without prior written authorization is
strictly prohibited.
Changing the Menu Strip on a
(FASTRON.) VC-210 Process
Controller
1
• Turn off the fryer power.
2
• With a flat screwdriver, remove the two screws that secure the
bezel of the VC-210 in place. Remove the bezel.
3
• Remove the existing menu strip(s) by lifting the tab and
pulling the menu strip out from the right side of the controller.
4
• Using the tab as a guide, slide the new menu strip in.
5
• Replace the bezel and screws that secure it to the controller.
6
• Turn on the fryer power.
Replacement Parts List
Part Number Description
150-10202 1/4-20X3/4" SLOT RD HD BLK O
150-11025 NUT 1/4-20 TINNERMAN SPRING
214-50291 SHEETMETAL BEZEL
214-50660-57 OVERLAY
214-51003-57 MENU STRIP
