1-15
z Conversion of the bridge circuit
X0
Y0
Y1
X1
X2
This network structure is not
allowed in PLC program
Ö
X1
Y0
Y1
X0
X2
X2
X1
X0
ORG X 1
AND X 2
OR X 0
OUT Y 0
ORG X 0
AND X 2
OR X 1
OUT Y 1
